Camera
Image Sensor
1/3″ SONY Exmor 1.3 Megapixel CMOS Sensor
Scanning System
Progressive
Shutter Speed
1/60 – 1/60,000 sec.
Resolution
1000 TVL
S/N Ratio
52dB
Effective Pixels
1305 (H) x 1049 (V)
Minimum Illumination
0.00001 Lux (Sens-Up x64
Lens
Type
Vari-Focal
True Day / Night
Yes
Focal Range
6~50mm
Max. Aperture Ratio
ƒ1.2
DSP
DSP Version
S7
Menu Control
Joystick
Built-in
DIN Port
For use with optional CE-REMOTE
Connections
Composite Video Output
1 BNC Output
Remote Control Input
1 DIN Input
Power Requirements
Type
DC12V and AC24V
Power Consumption
DC12V: 3.6 Watts (0.3 Amp)
AC24V: 2.64 Watts (0.11 Amp)
Physical
Product Dimensions
5.74″ (Dia.) x 4.13″ (H)
145.8mm (Dia.) x 104.9mm (H)
Product Weight
1.75 lbs (793.787 g)
Materials
Housing
Aluminum
Dome
Polycarbonate
Environmental
Weather Rating
IP68
Operating Temperature
-20° to 122° F (-28.8° to 50° C)
Operating Humidity
0% to 95% RH
Standards
FCC
Part 15B, Class A
RoHS
Compliant
UL
Listed
What’s Included
Torx Wrench
4 Mounting Screws
4 Wall Anchors
Mounting Template
Focusing Tool
Warranty & Support
Warranty
3 Year Warranty w/1st Year Advance Replacement
Learn More
Technical Support
Free Lifetime Technical Support via Phone (1-800-549-6393)
Learn More
Vandal X: Assembled & Designed in the USA
Vandal X: IP68 Weather Rated Camera
